| Engine Model |
Yanmar 3TNV76 |
| Net Power |
17.7 hp |
| Gross Power |
24.3 hp |
| Displacement |
68.1 in3 |
| Rated Net Power - ISO 9249 |
17.7 HP |
| Operating Weight |
3241.0 lb |
| Operating Weight - With Cab |
3241.0 lb |
| Operating Weight - With Canopy and Extending Undercarriage |
3236.0 lb |
| Operating Weight - With Canopy |
3042.0 lb |
| Operating Weight - With Cab and Extending Undercarriage |
3435.0 lb |
| Note |
Weights do not include worktools. |
| Tail Swing Radius |
3.53 ft |
| Maximum Digging Depth - Dozer Blade Below Ground |
10.4 in |
| Maximum Reach - On the Ground |
11.93 ft |
| Width |
2.4 ft |
| Minimum Boom Swing Radius |
4.89 ft |
| Undercarriage Width - Retracted |
3.25 ft |
| Maximum Digging Height |
11.13 ft |
| Maximum Digging Radius |
12.14 ft |
| Maximum Swing Angle of Boom System to the Left |
73° |
| Maximum Lift of Dozer Blade Above Ground |
8.3 in |
| Maximum Swing Angle of Boom System to the Right |
49° |
| Maximum Vertical Digging Depth |
4.86 ft |
| Maximum Digging Depth |
7.25 ft |
| Height |
7.47 ft |
| Track Length |
4.79 ft |
| Undercarriage Width - Extended |
4.27 ft |
| Maximum Dumping Height |
7.88 ft |
| Gradeability |
30°/58% |
| Travel Speed - 1st Gear |
1.5 mile/h |
| Track Width |
9.06 in |
| Operating Pressure - Equipment |
2901.0 psi |
| Operating Pressure - Travel |
2901.0 psi |
| Operating Pressure - Swing |
2176.0 psi |
| Maximum Stick Force |
1596.0 lb |
| Maximum Bucket Force |
3597.0 lb |
| Pump Flow at 2,200 rpm |
9.2 gal/min |
| Width |
38.6 in |
| Height |
9.1 in |
| Dig Depth |
10.4 in |
| Lift Height |
8.3 in |
| Fuel Tank Capacity |
6.3 gal |
| Hydraulic Tank Capacity |
5.3 gal (US) |
| Stick Length - Standard |
37.1 in |
| Stick Length - Long |
43.2 ft |
| Machine Overhang |
16.7 in |
| Minimum Boom Swing Radius |
4.89 ft |
| Tail Swing Radius |
3.53 ft |
| Height |
7.47 ft |
| Maximum Digging Radius |
12.63 ft |
| Maximum Digging Height |
11.51 ft |
| Maximum Digging Depth - Dozer Blade Below Ground |
10.4 in |
| Width |
2.4 ft |
| Track Length |
4.79 ft |
| Maximum Vertical Digging Depth |
5.33 ft |
| Travel Speed - 2nd Gear |
2.5 mile/h |
| Maximum Swing Angle of Boom System to the Right |
49° |
| Maximum Lift of Dozer Blade Above Ground |
8.3 in |
| Maximum Digging Depth |
7.78 ft |
| Maximum Reach - On the Ground |
12.44 ft |
| Undercarriage Width - Extended |
4.27 ft |
| Maximum Swing Angle of Boom System to the Left |
73° |
| Undercarriage Width - Retracted |
3.25 ft |
| Maximum Dumping Height |
8.26 ft |
