| Rated Net Power - 1,800 rpm - SAE J1349 (Performance Power Mode: Range 1-4) |
137.0 HP |
| Engine Model |
Cat® C7.1 |
| Maximum Gross Power - ISO 14396 (DIN) (Performance Power Mode: Range 1-4) |
143.0 HP |
| Net Power |
137.0 hp |
| Maximum Gross Power - ISO 14396 (Performance Power Mode: Range 1-4) |
141.0 HP |
| Bucket Capacities |
1.7-5.0 m3 (2.3-6.5 yd3) |
| Operating Weight |
26490.0 lb |
| Maximum Gross Power |
143.0 HP |
| ROPS |
SAE J1040 MAY94, ISO 3471-1994. |
| FOPS |
SAE J/ISO 3449 APR98, Level II, ISO 3449 1992 Level II. |
| Displacement (Performance Power Mode: Speed Range 1-4) |
427.0 in³ |
| Rated Net Power - 1,600 rpm - SAE J1349 (Standard Power Mode: Range 1-3*) |
131.0 HP |
| Maximum Gross Torque - ISO 14396 (Standard Power Mode: Range 1-3*) |
534.0 ft·lbf |
| Hydraulic Tank |
23.8 gal |
| Notes |
Factory default is 7 km/h (4.4 mph). |
| Cooling System |
8.5 gal |
| Note (1) |
Declared dynamic operator sound pressure level is 72 dB(A) when “ISO 6396:2008” is used to measure value for an enclosed cab. |
| Other Choices Vary by Region (2) |
17.5 R25, radial (L-2); 17.5 R25, radial (L-5); 550/65 R25 radial (L-3); Flexport™ Gen II; Skidder/Agriculture |
| Maximum Net Torque - SAE J1349 (Performance Power Mode: Range 1-4) |
519.0 lb/ft |
| Maximum Steering Torque - 40° (Full Turn) |
27747.0 ft·lbf |
| Steering Articulation Angle - Each Direction |
40° |
| Maximum Flow - Steering Pump |
33.0 gal/min |
| Number of Steering Wheel Turns - Full Left to Full Right or Full Right to Full Left |
3.5 turns |
| Hydraulic Cycle Time - Standard Mode at 1,600 rpm - Total Cycle Time |
10.6 s |
| Emissions |
Engine meets Tier 3/Stage IIIA equivalent emission standards. |
| Rated Net Power - 1,800 rpm - ISO 9249 (DIN) (Performance Power Mode: Range 1-4) |
140.0 HP |
| Hydraulic Cycle Time - Standard Mode at 1,600 rpm - Float Down, Maximum Lift to Ground Level |
2.6 s |
| Maximum Flow - Implement Pump - 4th Function Maximum Flow* |
40.0 gal/min |
| Note |
*Creeper control allows max. speed range adjustability from 1 km/h (0.6 mph) to 13 km/h (8 mph) in Range 1 through sec. display. |
| Note (2) |
In certain applications, the loader's productive capabilities may exceed the tire's tonnes-km/h (ton-mph) capabilities. |
| Forward and Reverse - Range 2 |
8.0 mile/h |
| Transmission - Gear Box |
2.2 gal (US) |
| Hydraulic Cycle Time - Standard Mode at 1,600 rpm - Raise, Ground Level to Maximum Lift |
6.3 s |
| Hydraulic Oil |
42.3 gal |
| Fuel Tank |
51.5 gal |
| Hydraulic Cycle Time - Performance Mode at 1,800 rpm - Float Down, Maximum Lift to Ground Level |
2.6 s |
| Relief Pressure - Tilt Cylinder - 3rd Function Maximum Working Pressure |
3771.0 psi |
| Note |
*Range 4 power is boosted to be the same as Performance Mode. |
| Forward and Reverse - Range 1* |
1-13 km/h (0.6-8 mph) |
| Maximum Flow - Implement Pump - 3rd Function* |
40.0 gal/min |
| Note (2) |
A semi-cab option is available. |
| Maximum Net Torque - SAE J1349 (Standard Power Mode: Range 1-3*) |
519.0 ft·lbf |
| Hydraulic Cycle Time - Dump |
|
| Maximum Steering Torque - 0° (Straight Machine) |
37155.0 ft·lbf |
| Note (2) |
The measurement was conducted at 70% of the maximum engine cooling fan speed, with the cab doors and cab windows closed. |
| Maximum Flow - Implement Pump |
40.0 gal/min |
| Operating Weight - 20.5 Tires |
26490.0 lb |
| Front Axles |
5.5 gal (US) |
| Hydraulic Cycle Time - Performance Mode at 1,800 rpm - Total Cycle Time |
9.5 s |
| Relief Pressure - Tilt Cylinder - 4th Function Maximum Working Pressure |
3771.0 psi |
| Engine Crankcase |
5.2 gal |
| Steering Cycle Times - Full Left to Full Right - At 1,800 rpm: 90 rpm Steering Wheel Speed |
2.4 s |
| Displacement (Standard Power Mode: Speed Range 1-3*) |
427.0 in³ |
| Hydraulic Cycle Time - Performance Mode at 1,800 rpm - Raise, Ground Level to Maximum Lift |
5.4 s |
| Other Choices Vary by Region (1) |
20.5 R25, radial (L-2); 20.5 R25 radial (L-3); 20.5 R25, radial (L-5); 20.5-25 12PR (L-2); 20.5-25 12PR (L-3); 20.5-25 12PR (L-5) |
| Rated Net Power - 1,600 rpm - ISO 9249 (DIN) (Standard Power Mode: Range 1-3*) |
135.0 HP |
| Relief Pressure - Tilt Cylinder |
4061.0 psi |
| Maximum Working Pressure - Steering Pump |
3500.0 psi |
| Forward and Reverse - Range 4 |
25.0 mile/h |
| Maximum Gross Power - ISO 14396 (DIN) (Standard Power Mode: Range 1-3*) |
137.0 HP |
| Hydraulic Cycle Time - Performance Mode at 1,800 rpm - Dump, at Maximum Lift Height |
1.5 s |
| Maximum Net Torque - ISO 9249 (1977)/EEC 80/1269 (Performance Power Mode: Range 1-4) |
524.0 lb/ft |
| Front |
Fixed; Open differential (standard); Locking differential (optional) |
| Hydraulic Cycle Time - Standard Mode at 1,600 rpm - Dump, at Maximum Lift Height |
1.7 s |
| Forward and Reverse - Range 3 |
17.0 mile/h |
| Maximum Gross Torque - ISO 14396 (Performance Power Mode: Range 1-4) |
534.0 lb/ft |
| Rear Axles |
5.5 gal (US) |
| Rear |
Oscillating ±11 degrees; Open differential (standard); Limited slip differential (optional in some regions) |
| Maximum Gross Power - ISO 14396 (Standard Power Mode: Range 1-3*) |
135.0 HP |
| Note |
*Adjustable from 20% to 100% of maximum flow through the secondary display, when equipped. |
| Operating Weight - 17.5 Tires |
25281.0 lb |
| Note (1) |
Other tire choices are available. Contact your Cat dealer for details. |
| Note (1) |
Cab and Rollover Protective Structures (ROPS) are standard. |
| Bucket Capacities - Light Material |
3.1-5.0 m3 (4.0-6.5 yd3) |
| Note (3) |
Caterpillar recommends that you consult a tire supplier to evaluate all conditions before selecting a tire model. |
| Bucket Capacities - General Purpose |
1.7-2.5 m3 (2.2-3.2 yd3) |
| Standard Size |
17.5 R25, radial (L-3) |
| Maximum Net Torque - ISO 9249 (1977)/EEC 80/1269 (Standard Power Mode: Range 1-3*) |
524.0 ft·lbf |
| Note (3) |
The declared exterior sound power level is 104 dB(A) when the value is measured according to “ISO 6395:2008.” |
