| Bucket Capacities |
2.5-9.2 m? (3.25-12.0 yd3) |
| Engine Model |
Cat? C9.3 ACERT? |
| Bore |
4.53 in |
| Stroke |
5.87 in |
| Displacement |
568.0 in3 |
| Forward 1 |
4.04 mph |
| Forward 2 |
8.08 mph |
| Forward 3 |
14.6 mph |
| Forward 4 |
24.54 mph |
| Reverse 1 |
4.41 mph |
| Reverse 2 |
8.95 mph |
| Reverse 3 |
16.09 mph |
| Reverse 4 |
24.54 mph |
| Front |
Fixed |
| Rear |
Oscillating ?13 degrees |
| Maximum Single-Wheel Rise and Fall |
19.8 in |
| Brakes |
Brakes meet ISO 3450 standards |
| Cooling System |
18.9 gal |
| Crankcase |
6.5 gal |
| Transmission |
15.5 gal |
| Hydraulic Tank |
33.0 gal |
| ROPS/FOPS |
ROPS/FOPS meet ISO 3471 and ISO 3449 Level II standards |
| Breakout Force |
38892.0 lbf |
| Hydraulic Cycle Time with Rated Payload - Dump, at Maximum Raise |
1.4 Seconds |
| Exterior Sound Power Level - ISO 6395:2008 (European Union Directive "2000/14/EC" as amended by "2005/88/EC") |
108.0 dB(A) |
| Maximum Net Power - SAE J1349 |
280.0 hp |
| Fuel Tank |
82.7 gal |
| Implement System - Maximum Pump Output at 2,200 rpm |
95.1 gal/min |
| Max. Gross Power (1,800 rpm) - SAE J1995 (metric) |
315.0 hp |
| Differential - Final Drives - Front |
15.1 gal (US) |
| Maximum Power - 1,800 rpm - ISO 14396 - Metric |
311.0 HP |
| Peak Gross Torque - 1,200 rpm - SAE J1995 |
1179.0 ft-lb |
| Maximum Power - ISO 14396 - Metric |
311.0 HP |
| Operator Sound Pressure Level (ISO 6396:2008) |
69.0 dB(A) |
| Note (1) |
The sound values are for specific operating conditions only. |
| Maximum Net Torque - 1,000 rpm - ISO 9249 |
1126.0 ft·lbf |
| Rear |
Hearing protection may be needed when the doors and/or windows are open for extended periods or in a noisy environment. |
| Exterior Sound Power Level (SAE J88:2013) |
76.0 dB(A) |
| Differential - Final Drives - Rear |
15.1 gal (US) |
| Operating Weight |
51191.0 lb |
| Implement System - Maximum Flow - Optional 3rd/4th Function |
63.4 gal/min |
| Note |
Maximum travel speed in standard vehicle with empty bucket and standard L3 tires with 826 mm roll radius. |
| Implement System - Maximum Pressure - Optional 3rd/4th Function |
3159.0 psi |
| Implement System - Maximum Operating Pressure |
4496.0 psi |
| Hydraulic Cycle Time with Rated Payload - Lower, Empty, Float Down |
2.6 Seconds |
| Static Tipping Load - Full 37° Turn - No Tire Deflection |
34882.0 lb |
| Note |
For 4.2 m3 general purpose buckets with BOCE. |
| Maximum Net Power - 1,700 rpm - ISO 9249 - Metric |
280.0 HP |
| Net Power – ISO 9249 |
280.0 hp |
| Note (2) |
Machine and operator sound levels will vary at different engine and/or cooling fan speeds. |
| DEF Tank |
4.4 gal |
| Air Conditioning |
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.6 kg of refrigerant which has a CO2 equivalent of 2.288 metric tonnes. |
| Hydraulic Cycle Time with Rated Payload - Total |
10.1 Seconds |
| Peak Torque (1,200 rpm) - ISO 14396 |
1166.0 lb ft |
| Note |
*Must meet the requirements outlined in ISO 22241-1. |
| Static Tipping Load - Full 37° Turn - With Tire Deflection |
32337.0 lb |
| Note (3) |
Hearing protection may be needed when the machine is operated with a cabin that is not properly maintained. |
| Implement Pump Type |
Variable Displacement Piston |
| Hydraulic Cycle Time with Rated Payload - Raise from Carry Position |
6.1 Seconds |
| Emissions |
Cat engine with ACERT Technology meets Stage IV emission standards. |
