| Net Power |
541.0 hp |
| Engine Model |
Cat® C18 ™ |
| Bore |
5.7 in |
| Stroke |
7.2 in |
| Displacement |
1105.0 in3 |
| Torque Rise |
58.0 % |
| Rated Speed |
1700/min |
| Peak Torque @ 1,200 rpm |
2104.0 lb ft |
| Net Power – SAE J1349 |
541.0 hp |
| Peak Power Speed |
1500/min |
| Peak Power Speed @ 1,500 rpm: Gross - ISO 14396 |
580.0 hp |
| Gross (ISO 14396) |
580.0 hp |
| Peak Power Speed @ 1,500 rpm: Gross - SAE J1995 |
588.0 hp |
| Emissions |
U.S. EPA Tier 4 Final/EU Stage IV OR Tier 3/Stage IIIA Equivalent OR Tier 2/Stage II Equivalent |
| Peak Power Speed @ 1,500 rpm: Net Power - SAE J1349 |
541.0 hp |
| Operating Weight |
112574.0 lb |
| Bucket Capacity Range |
4.7-13 m3 (6.2-17 yd3) |
| Rated Payload - Standard (Quarry Face) |
12.5 tons |
| Cat Truck Match - High Lift |
773～775 |
| Rated Payload - Loose Material |
16.0 t |
| Cat Truck Match - Standard |
770～772 |
| Transmission - type |
Cat-Planetenlastschaltgetriebe |
| Forward 1 |
4.0 mph |
| Forward 2 |
7.2 mph |
| Forward 3 |
12.7 mph |
| Forward 4 |
21.6 mph |
| Reverse 1 |
4.7 mph |
| Reverse 2 |
8.3 mph |
| Reverse 3 |
14.4 mph |
| Direct Drive - Reverse 2 |
8.9 mile/h |
| Direct Drive - Reverse 3 |
15.8 mph |
| Direct Drive - Forward 2 |
7.8 mile/h |
| Direct Drive - Reverse 1 |
5.0 mile/h |
| Direct Drive - Forward 1 |
Lock-up disabled |
| Direct Drive - Forward 3 |
13.9 mph |
| Direct Drive - Forward 4 |
24.4 mph |
| Maximum Flow |
13.7 gal/min |
| Maximum Flow at 1,400-1,860 rpm |
153.0 gal/min |
| Lift/Tilt System |
Variable displacement piston |
| Lift/Tilt System - Pump |
269 mm × 685 mm (8.7 in × 27 in) |
| Relief Valve Setting |
551.0 psi |
| Tilt Cylinder - Stroke* |
4757.0 in |
| Max Flow at 1,710 rpm (3x) |
gal/min |
| Lift/Tilt System - Circuit |
210 mm × 1050 mm (8.7 in × 41.3 in) |
| Lift Cylinder - Bore* |
in |
| Fuel Tank |
188.0 gal |
| Cooling System |
31.7 gal |
| Crankcase |
15.9 gal |
| Transmission |
31.7 gal |
| Hydraulic System - Tank Only |
63.4 gal (US) |
| Differential - Final Drives - Rear |
49.1 gal (US) |
| Hydraulic System Factory Fill |
125.5 gal |
| Diesel Exhaust Fluid Tank (For Tier 4 Final/Stage IV Only) |
8.7 gal (US) |
| Differential - Final Drives - Front |
49.1 gal (US) |
| Bucket Capacities |
4.7-13 m3 (6.2-17 yd3) |
| Front |
Fixed |
| Rear |
Trunnion |
| Oscillation Angle |
13 ° |
| Brakes |
SAE J1473 OKT90, ISO 3450:1992 |
| Steering System - Pump |
Piston, variable displacement |
| Total Steering Angle |
86 ° |
| Maximum Flow |
71.3 gal/min |
| Relief Valve Setting - Steering |
4351.0 psi |
| Steering Cycle Times - High Idle |
3.4 s |
| Steering System - Circuit |
Pilot, load sensing |
| Steering Cycle Times - Low Idle |
5.6 s |
| Total Hydraulic Cycle Time (empty bucket) |
18.2 Seconds |
| Lower Float Down |
3.5 Seconds |
| Rackback |
4.5 Seconds |
| Raise |
8.0 Seconds |
| Dump |
2.2 Seconds |
| Operator Sound Level (ISO 6396) |
72.0 dB(A) |
| Machine Sound Level (ISO 6395) |
111.0 dB(A) |
| Machine Sound Level (ISO 6395) |
109.0 dB(A) |
| Operator Sound Level (ISO 6396) |
72.0 dB(A) |
| Operator Sound Level (ISO 6396) |
72.0 dB(A) |
| Machine Sound Level (ISO 6395) |
112.0 dB(A) |
| Machine Sound Level (ISO 6395) |
110.0 dB(A) |
| Coolant (Validated by Test Cell Fill Quantities) |
33.0 gal (US) |
| Transmission - Validated by Test Cell Fill Quantities |
29.0 gal (US) |
| Operator Sound Level ( ISO 6396) |
73.0 dB(A) |
