| Engine Model |
Cat® C15 ACERT™ |
| Flywheel Power |
317.0 hp |
| Operating Weight |
87733.0 lb |
| Shoe Type |
|
| Shoes/Side |
|
| Track Rollers/Side |
|
| Number of Carrier Rollers |
|
| Bore |
5.4 in |
| Stroke |
6.75 in |
| Displacement |
928.0 in3 |
| 1 Forward |
2.1 mph |
| 2 Forward |
3.8 mph |
| 3 Forward |
6.6 mph |
| 1 Reverse |
2.8 mph |
| 2 Reverse |
5.0 mph |
| 3 Reverse |
8.8 mph |
| 1 Forward - Drawbar Pull (1000) |
139.0 lbf |
| 2 Forward - Drawbar Pull (1000) |
76.0 lbf |
| 3 Forward - Drawbar Pull (1000) |
42.0 lbf |
| Fuel Tank |
170.0 gal |
| Cooling System |
20.3 gal |
| Engine Crankcase* |
10.0 gal |
| Final Drives (each) |
3.3 gal |
| Roller Frames (each) |
17.2 gal |
| Pivot Shaft Compartment |
10.6 gal |
| Pump Type |
Piston-type, Variable Displacement |
| Pump Output (Steering) |
73.0 gal/min |
| Pump Output (Implement) |
60.0 gal/min |
| Tilt Cylinder Rod End Flow |
34.0 gal/min |
| Tilt Cylinder Head End Flow |
45.0 gal/min |
| Bulldozer Relief Valve Setting |
3480.0 psi |
| Tilt Cylinder Relief Valve Setting |
3480.0 psi |
| Ripper (Lift) Relief Valve Setting |
3480.0 psi |
| Ripper (Pitch) Relief Valve Setting |
3480.0 psi |
| Steering |
5700.0 psi |
| Winch Model |
PA14OVS |
| Weight* |
3947.0 lb |
| Oil Capacity |
4.0 gal |
| Increased Tractor Length |
22.2 in |
| Winch Case Width |
45.6 in |
| Drum Width |
12.6 in |
| Flange Diameter |
18.0 in |
| ROPS/FOPS |
Standards |
| Drum Capacity - Optional Cable |
193.0 ft |
| Cable Ferrule Sizes - Outside Diameter |
2.36 in |
| Drum Capacity - Recommended Cable Size |
276.0 ft |
| Powertrain |
41.0 gal |
| Cable Ferrule Sizes - Length |
2.76 in |
| Hydraulic Tank |
19.8 gal |
| Recommended Cable Size |
1.13 in |
| Optional Cable Size |
1.25 in |
| Total Operating Weight* (with SU-Blade and Ripper) |
89479.0 lb |
| Capacity (SAE J1265) |
6.1 yd3 |
| Winch Length |
56.3 in |
| Operating Weight - Standard |
87733.0 lb |
| Shipping Weight - Standard |
67219.0 lb |
| Engine Power (Maximum) - ISO 14396 |
359.0 hp |
| Engine Power (Maximum) - ISO 14396 (DIN) |
364.0 hp |
| Net Power (Maximum) - ISO 9249/SAE J1349 |
333.0 hp |
| Net Power (Maximum) - ISO 9249/SAE J1349 (DIN) |
338.0 hp |
| Engine Power (Maximum) - SAE J1995 |
363.0 hp |
| Width of Shoe |
24.0 in |
| Grouser Height |
3.1 in |
| Pitch |
8.5 in |
| Ground Clearance |
24.1 in |
| Track Gauge |
82.0 in |
| Length of Track on Ground |
126.0 in |
| Ground Contact Area |
6060.0 in2 |
| Ground Pressure (ISO 16754) |
13.0 psi |
| Grouser Height |
3.1 in |
| Pitch |
8.5 in |
| Ground Clearance |
24.1 in |
| Track Gauge |
92.0 in |
| Length of Track on Ground |
126.0 in |
| Ground Contact Area |
9593.0 in2 |
| Ground Pressure (ISO 16754) |
7.8 psi |
| Width of Shoe |
38.0 in |
| Capacity (SAE J1265) |
11.1 yd3 |
| Width (over end bits) |
14.8 ft |
| Height |
5.32 ft |
| Digging Depth |
22.7 in |
| Ground Clearance |
48.1 in |
| Maximum Tilt |
36.0 in |
| Weight* (without hydraulic controls) |
11345.0 lb |
| Total Operating Weight** (with Blade and Single-Shank Ripper) |
83324.0 lb |
| Operating Weight - LGP |
83324.0 lb |
| Shipping Weight - LGP |
74075.0 lb |
| Net Power (Rated) - ISO 9249/SAE J1349 |
317.0 hp |
| Net Power (Rated) - ISO 9249/SAE J1349 (DIN) |
322.0 hp |
| Shoe Type |
Moderate Service |
| Sound |
Standards |
| Track Rollers per Side |
8 |
| Track Rollers per Side |
8 |
| Shoes/Side |
44 |
| Global Emissions |
U.S. Tier 4 Interim/EU Stage IIIB/Japan MLIT Step 4 |
| Type |
8SU LGP |
| Shoe Type |
Moderate Service |
| Shoes/Side |
44 |
| Net Power - DIN 70020 |
|
| Brakes |
Standards |
| Type |
Single-Shank, Adjustable Parallelogram |
| Number of Pockets |
1 |
| Maximum Clearance Raised (under tip, pinned in bottom hole) |
25.0 in |
| Maximum Penetration (standard tip) |
44.4 in |
| Maximum Penetration Force (shank vertical) |
28620.0 lb |
| Pry out Force |
50070.0 lb |
| Weight (without hydraulic controls) |
9005.0 lb |
| Total Operating Weight* (with SU-Blade and Ripper) |
87733.0 lb |
| Type |
Multi-Shank, Adjustable Parallelogram |
| Number of Pockets |
3 |
| Overall Beam Width |
97.0 in |
| Maximum Clearance Raised (under tip, pinned in bottom hole) |
23.35 in |
| Maximum Penetration (standard tip) |
30.7 in |
| Maximum Penetration Force (shank vertical) |
27920.0 lb |
| Pry out Force (Multi-Shank Ripper with one tooth) |
51230.0 lb |
| Weight (one shank, without hydraulic controls) |
10752.0 lb |
| Additional Shank |
732.0 lb |
| Type |
8SU |
| Capacity (SAE J1265) |
11.4 yd3 |
| Width (over end bits) |
12.9 ft |
| Height |
5.5 ft |
| Digging Depth |
22.6 in |
| Ground Clearance |
48.2 in |
| Maximum Tilt |
34.8 in |
| Weight* (without hydraulic controls) |
10557.0 lb |
| Total Operating Weight** (with Blade and Single-Shank Ripper) |
87733.0 lb |
| Type |
8U |
| Capacity (SAE J1265) |
15.3 yd3 |
| Width (over end bits) |
14.0 ft |
| Height |
5.71 ft |
| Digging Depth |
22.6 in |
| Ground Clearance |
48.2 in |
| Maximum Tilt |
37.5 in |
| Weight* (without hydraulic controls) |
11800.0 lb |
| Total Operating Weight** (with Blade and Single-Shank Ripper) |
88974.0 lb |
| Type |
8A |
| Width (over end bits) |
16.3 ft |
| Height |
3.85 ft |
| Digging Depth |
24.7 in |
| Ground Clearance |
51.5 in |
| Maximum Tilt |
28.7 in |
| Weight* (without hydraulic controls) |
12035.0 lb |
| Total Operating Weight** (with Blade and Single-Shank Ripper) |
89210.0 lb |
